Compare pressure range, output and connection before choosing a sensor. PSO mounting and connection accessories are listed separately.
120 models shown
No matching models. Try a shorter entry or choose Show all models.
| Model | Pressure range | Control / analog output | Connection | Supply |
|---|---|---|---|---|
| PSA-01-NPT1/8 | 0 to 100.0 kPa | 2 NPN/1-5 VDC Out | NPT1/8 | 12-24 VDC |
| PSA-01-Rc1/8 | 0 to 100.0 kPa | 2 NPN/1-5 VDC Out | Rc1/8 | 12-24 VDC |
| PSA-01P-NPT1/8 | 0 to 100.0 kPa | 2 PNP/1-5 VDC Out | NPT1/8 | 12-24 VDC |
| PSA-01P-Rc1/8 | 0 to 100.0 kPa | 2 PNP/1-5 VDC Out | Rc1/8 | 12-24 VDC |
| PSA-1-NPT1/8 | 0 to 1000 kPa | 2 NPN/1-5 VDC Out | NPT1/8 | 12-24 VDC |
| PSA-1-Rc1/8 | 0 to 1000 kPa | 2 NPN/1-5 VDC Out | Rc1/8 | 12-24 VDC |
| PSA-1P-NPT1/8 | 0 to 1000 kPa | 2 PNP/ 1-5 VDC Out | NPT1/8 | 12-24 VDC |
| PSA-1P-Rc1/8 | 0 to 1000 kPa | 2 PNP/ 1-5 VDC Out | Rc1/8 | 12-24 VDC |
| PSA-C01-NPT1/8 | -100 to 100kPa | 2 NPN/1-5 VDC Out | NPT1/8 | See model details |
| PSA-C01-Rc1/8 | -100 to 100kPa | 2 NPN/1-5 VDC Out | Rc1/8 | 12-24 VDC |
| PSA-C01P-NPT1/8 | -100 to 100kPa | 2 PNP/1-5 VDC Out | NPT1/8 | 12-24 VDC |
| PSA-C01P-Rc1/8 | -100 to 100kPa | 2 PNP/1-5 VDC Out | Rc1/8 | 12-24 VDC |
| PSA-V01-NPT1/8 | 0 to -101.3 kPa | 2 NPN/1-5 VDC Out | NPT1/8 | See model details |
| PSA-V01-Rc1/8 | 0 to -101.3 kPa | 2 NPN/1-5 VDC Out | Rc1/8 | 12-24 VDC |
| PSA-V01P-NPT1/8 | 0 to -101.3 kPa | 2 PNP/1-5 VDC Out | NPT1/8 | 12-24 VDC |
| PSA-V01P-Rc1/8 | 0 to -101.3 kPa | 2 PNP/1-5 VDC Out | Rc1/8 | 12-24 VDC |
| PSAN-01CA-NPT1/8 | 0.0 to 100.0kPa | NPN open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-01CA-RC1/8 | 0.0 to 100.0kPa | NPN open collector; Current output(DC4-20mA) | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-01CH-NPT1/8 | 0.0 to 100.0kPa | NPN open collector; Hold/Auto shift input | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-01CH-RC1/8 | 0.0 to 100.0kPa | NPN open collector; Hold/Auto shift input | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-01CPA-NPT1/8 | 0.0 to 100.0kPa | PNP open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-01CPA-RC1/8 | 0.0 to 100.0kPa | PNP open collector; Current output(DC4-20mA) | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-01CPH-NPT1/8 | 0.0 to 100.0kPa | PNP open collector; Hold/Auto shift input | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-01CPH-RC1/8 | 0.0 to 100.0kPa | PNP open collector; Hold/Auto shift input | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-01CPV-NPT1/8 | 0.0 to 100.0kPa | PNP open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-01CPV-RC1/8 | 0.0 to 100.0kPa | PNP open collector; Voltage(1-5VDC ) output | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-01CV-NPT1/8 | 0.0 to 100.0kPa | NPN open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-01CV-RC1/8 | 0.0 to 100.0kPa | NPN open collector; Voltage(1-5VDC ) output | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-1CA-NPT1/8 | 0 to 1,000kPa | NPN open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-1CA-RC1/8 | 0 to 1,000kPa | NPN open collector; Current output(DC4-20mA) | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-1CH-NPT1/8 | 0 to 1,000kPa | NPN open collector; Hold/Auto shift input | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-1CH-RC1/8 | 0 to 1,000kPa | NPN open collector; Hold/Auto shift input | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-1CPA-NPT1/8 | 0 to 1,000kPa | PNP open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-1CPA-RC1/8 | 0 to 1,000kPa | PNP open collector; Current output(DC4-20mA) | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-1CPH-NPT1/8 | 0 to 1,000kPa | PNP open collector; Hold/Auto shift input | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-1CPH-RC1/8 | 0 to 1,000kPa | PNP open collector; Hold/Auto shift input | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-1CPV-NPT1/8 | 0 to 1,000kPa | PNP open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-1CPV-RC1/8 | 0 to 1,000kPa | PNP open collector; Voltage(1-5VDC ) output | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-1CV-NPT1/8 | 0 to 1,000kPa | NPN open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-1CV-RC1/8 | 0 to 1,000kPa | NPN open collector; Voltage(1-5VDC ) output | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-C01CA-NPT1/8 | -101.3 to 100.0kPa | NPN open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-C01CA-RC1/8 | -101.3 to 100.0kPa | NPN open collector; Current output(DC4-20mA) | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-C01CH-NPT1/8 | -101.3 to 100.0kPa | NPN open collector; Hold/Auto shift input | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-C01CH-RC1/8 | -101.3 to 100.0kPa | NPN open collector; Hold/Auto shift input | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-C01CPA-NPT1/8 | -101.3 to 100.0kPa | PNP open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-C01CPA-RC1/8 | -101.3 to 100.0kPa | PNP open collector; Current output(DC4-20mA) | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-C01CPH-NPT1/8 | -101.3 to 100.0kPa | PNP open collector; Hold/Auto shift input | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-C01CPH-RC1/8 | -101.3 to 100.0kPa | PNP open collector; Hold/Auto shift input | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-C01CPV-NPT1/8 | -101.3 to 100.0kPa | PNP open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-C01CPV-RC1/8 | -101.3 to 100.0kPa | PNP open collector; Voltage(1-5VDC ) output | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-C01CV-NPT1/8 | -101.3 to 100.0kPa | NPN open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-C01CV-RC1/8 | -101.3 to 100.0kPa | NPN open collector; Voltage(1-5VDC ) output | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L01CA-NPT1/8 | 0.0 to 100.0kPa | NPN open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L01CA-R1/8 | 0.0 to 100.0kPa | NPN open collector; Current output(DC4-20mA) | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L01CH-R1/8 | 0.0 to 100.0kPa | NPN open collector; Hold/Auto shift input | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L01CPA-NPT1/8 | 0.0 to 100.0kPa | PNP open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L01CPA-R1/8 | 0.0 to 100.0kPa | PNP open collector; Current output(DC4-20mA) | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L01CPH-R1/8 | 0.0 to 100.0kPa | PNP open collector; Hold/Auto shift input | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L01CPV-NPT1/8 | 0.0 to 100.0kPa | PNP open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L01CPV-R1/8 | 0.0 to 100.0kPa | PNP open collector; Voltage(1-5VDC ) output | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L01CV-NPT1/8 | 0.0 to 100.0kPa | NPN open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L01CV-R1/8 | 0.0 to 100.0kPa | NPN open collector; Voltage(1-5VDC ) output | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L1CA-NPT1/8 | 0 to 1,000kPa | NPN open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L1CA-R1/8 | 0 to 1,000kPa | NPN open collector; Current output(DC4-20mA) | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L1CH-R1/8 | 0 to 1,000kPa | NPN open collector; Hold/Auto shift input | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L1CPA- NPT 1/8 | 0 to 1,000kPa | PNP open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L1CPA-R1/8 | 0 to 1,000kPa | PNP open collector; Current output(DC4-20mA) | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L1CPH-R1/8 | 0 to 1,000kPa | PNP open collector; Hold/Auto shift input | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L1CPV-NPT1/8 | 0 to 1,000kPa | PNP open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L1CPV-R1/8 | 0 to 1,000kPa | PNP open collector; Voltage(1-5VDC ) output | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L1CV-NPT1/8 | 0 to 1,000kPa | NPN open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-L1CV-R1/8 | 0 to 1,000kPa | NPN open collector; Voltage(1-5VDC ) output | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LC01CA-NPT1/8 | -101.3 to 100.0kPa | NPN open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LC01CA-R1/8 | -101.3 to 100.0kPa | NPN open collector; Current output(DC4-20mA) | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LC01CH-R1/8 | -101.3 to 100.0kPa | NPN open collector; Hold/Auto shift input | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LC01CPA-NPT1/8 | -101.3 to 100.0kPa | PNP open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LC01CPA-R1/8 | -101.3 to 100.0kPa | PNP open collector; Current output(DC4-20mA) | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LC01CPH-R1/8 | -101.3 to 100.0kPa | PNP open collector; Hold/Auto shift input | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LC01CPV-NPT1/8 | -101.3 to 100.0kPa | PNP open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LC01CPV-R1/8 | -101.3 to 100.0kPa | PNP open collector; Voltage(1-5VDC ) output | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LC01CV-NPT1/8 | -101.3 to 100.0kPa | NPN open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LC01CV-R1/8 | -101.3 to 100.0kPa | NPN open collector; Voltage(1-5VDC ) output | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LV01CA-NPT1/8 | 0.0 to -101.3kPa | NPN open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LV01CA-R1/8 | 0.0 to -101.3kPa | NPN open collector; Current output(DC4-20mA) | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LV01CH-NPT1/8 | 0.0 to -101.3kPa | NPN open collector; Hold/Auto shift input | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LV01CH-R1/8 | 0.0 to -101.3kPa | NPN open collector; Hold/Auto shift input | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LV01CPA-NPT1/8 | 0.0 to -101.3kPa | PNP open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LV01CPA-R1/8 | 0.0 to -101.3kPa | PNP open collector; Current output(DC4-20mA) | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LV01CPH-NPT1/8 | 0.0 to -101.3kPa | PNP open collector; Hold/Auto shift input | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LV01CPH-R1/8 | 0.0 to -101.3kPa | PNP open collector; Hold/Auto shift input | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LV01CPV-NPT1/8 | 0.0 to -101.3kPa | PNP open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LV01CPV-R1/8 | 0.0 to -101.3kPa | PNP open collector; Voltage(1-5VDC ) output | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LV01CV-NPT1/8 | 0.0 to -101.3kPa | NPN open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-LV01CV-R1/8 | 0.0 to -101.3kPa | NPN open collector; Voltage(1-5VDC ) output | R1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-V01CA-NPT1/8 | 0.0 to -101.3kPa | NPN open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-V01CA-RC1/8 | 0.0 to -101.3kPa | NPN open collector; Current output(DC4-20mA) | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-V01CH-NPT1/8 | 0.0 to -101.3kPa | NPN open collector; Hold/Auto shift input | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-V01CH-RC1/8 | 0.0 to -101.3kPa | NPN open collector; Hold/Auto shift input | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-V01CPA-NPT1/8 | 0.0 to -101.3kPa | PNP open collector; Current output(DC4-20mA) | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-V01CPA-RC1/8 | 0.0 to -101.3kPa | PNP open collector; Current output(DC4-20mA) | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-V01CPH-NPT1/8 | 0.0 to -101.3kPa | PNP open collector; Hold/Auto shift input | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-V01CPH-RC1/8 | 0.0 to -101.3kPa | PNP open collector; Hold/Auto shift input | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-V01CPV-NPT1/8 | 0.0 to -101.3kPa | PNP open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-V01CPV-RC1/8 | 0.0 to -101.3kPa | PNP open collector; Voltage(1-5VDC ) output | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-V01CV-NPT1/8 | 0.0 to -101.3kPa | NPN open collector; Voltage(1-5VDC ) output | NPT1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSAN-V01CV-RC1/8 | 0.0 to -101.3kPa | NPN open collector; Voltage(1-5VDC ) output | Rc1/8 | 12-24VDC ±10%(ripple P-P: max. 10%) |
| PSB-01 | 0 to 100.0 kPa | 2 NPN/1-5 VDC Out | See model details | 12-24 VDC |
| PSB-01P | 0 to 100.0 kPa | 2 PNP/1-5 VDC Out | See model details | 12-24 VDC |
| PSB-1 | 0 to 1000 kPa | 2 NPN/1-5 VDC Out | See model details | 12-24 VDC |
| PSB-1P | 0 to 1000 kPa | 2 PNP/ 1-5 VDC Out | See model details | 12-24 VDC |
| PSB-C01 | -100 to 100kPa | 2 NPN/1-5 VDC Out | See model details | 12-24 VDC |
| PSB-C01P | -100 to 100kPa | 2 PNP/1-5 VDC Out | See model details | 12-24 VDC |
| PSB-V01 | 0 to -101.3 kPa | 2 NPN/1-5 VDC Out | See model details | 12-24 VDC |
| PSB-V01P | 0 to -101.3 kPa | 2 PNP/1-5 VDC Out | See model details | 12-24 VDC |
| PSO-01 | Accessory | Panel Mount Bracket for PSA | — | — |
| PSO-02 | Accessory | Mounting Cover for PSA | — | — |
| PSO-B02 | Accessory | Panel Mount Bracket for PSAN | — | — |
| PSO-C01 | Accessory | Connector cable, for PSAN | — | — |
| PSO-P01 | Accessory | Mounting Cover for PSAN | — | — |
| PSO-Z01 | Accessory | M5 Gender for PSAN | — | — |
Open a model to review its full specifications and request a quote. Family pictures show representative models.
